WYA-Iron Pin Series

Classification： WYA

The capillary thermostat functions through its capillary sensing head, in which the volume of the temperature-sensing liquid changes with the temperature to automatically turns on and off the circuit. It is mainly used in the home appliance, electric heating equipment, refrigeration industry and other equipment to realize the goal of temperature control and protection. Safety Certification: CQC, CE, CB

Product Consulting

Detailed Description

Advantage

30 years’ experience of temperature control research, manufacture and customer service.

Achieved automatic mechanized production and integration of the supply chain.

Industry-leading production capacity. The annual production is over 300 million units and continuously increasing.

Stringent quality control and full inspection

Products are compliant with EU RoHs Directive and certified by CQC, ,VDE, UL, TUV, CE, CB.

Fast and flexible response of individual requirement, efficient customer service.

SPECIFICATIONS

Temperature Range	-35-320°C
Rated Voltage/Current/Frequency	250VAC 16A 50/60Hz
Electrical Strength	2000VAC/1min/0.5mA
Insulation Resistance	≥100MQ
Maximum Temperature Resistanceof the Main Body	125°C
Product Lifespan	100,000 cycles
Switch Type	Single Pole Single Throw (SPST),Single Pole Double Throw (SPDT)
Sleeve Length	50mm-600mm
Temperature Sensing Tube Length	44mm-120mm
Temperature Sensing Tube Diameter	Φ3/Φ4/Φ5/Φ6
Adjustment Shaft Length	8-30mm
Capillary Tube Length	400mm-3000mm
