KSD301-1 best ksd bimetal thermostat

Classification： KSD301-1

The bimetal (1/2 inch disc diameter) thermostat of KSD 301 Series is a small thermostat with shell. It is Single action and single throw, working on resistive loads. This thermostat is mainly used in the temperature control and protection of microwave ovens, electric kettles, coffee pots, water dispensers, disinfection cupboards, ovens and other kitchen appliances equipment.

Product Consulting

Detailed Description

Advantage

30 years’ experience of temperature control research, manufacture and customer service.

Achieved automatic mechanized production and integration of the supply chain.

Industry-leading production capacity. The annual production is over 300 million units and continuously increasing.

Stringent quality control and full inspection

Products are compliant with EU RoHs Directive and certified by CQC, ,VDE, UL, TUV, CE, CB.

Fast and flexible response of individual requirement, efficient customer service.

SPECIFICATIONS

Rated voltage	250V
Rated current	5A/10A/16A
Bimetal Disc	1/2 Inch/φ12.8mm
Operating Temperture Range	45°C-180°C/113°F-356°F
Reset type	Automatic Reset
Shell Material	Bakelite
Electric Strength	AC1500V 50/60hz-0.5mA/1min
Resistance	≤50mΩ
Insulation Resistance	≥100MΩ(DC500V)
Complies with RoHS and REACH

CERTIFICATION

The KSD Bimetal Thermostat is a high-performance, reliable temperature control device designed for a wide range of applications, including household appliances, automotive systems, and industrial equipment. This compact, bimetallic thermostat offers precise temperature regulation by using a bimetallic strip that bends or deflects with changes in temperature, triggering the switching mechanism to open or close electrical contacts.

With its robust construction and excellent durability, the KSD bimetal thermostat is engineered to provide long-lasting performance in various environments. The bimetallic design ensures quick and accurate temperature response, making it ideal for applications requiring precise thermal control. It operates over a wide temperature range and can be customized to meet specific temperature thresholds, providing versatility for different use cases.

The KSD bimetal thermostat is widely used in appliances such as electric irons, toasters, coffee makers, and refrigerators, as well as in automotive systems for engine and battery management. Its easy integration into existing systems, coupled with low power consumption, makes it an energy-efficient choice for modern devices.

Designed for both safety and performance, the KSD bimetal thermostat features high switching capacity and excellent thermal stability, ensuring reliable operation even under challenging conditions. Whether for personal or industrial use, it offers a cost-effective, dependable solution for accurate temperature control.
