KSD301-1

Classification： KSD301-1

The bimetal (1/2 inch disc diameter) thermostat of KSD 301 Series is a small thermostat with shell. It is Single action and single throw, working on resistive loads. This thermostat is mainly used in the temperature control and protection of microwave ovens, electric kettles, coffee pots, water dispensers, disinfection cupboards, ovens and other kitchen appliances equipment.

Product Consulting

Detailed Description

Advantage

30 years’ experience of temperature control research, manufacture and customer service.

Achieved automatic mechanized production and integration of the supply chain.

Industry-leading production capacity. The annual production is over 300 million units and continuously increasing.

Stringent quality control and full inspection

Products are compliant with EU RoHs Directive and certified by CQC, ,VDE, UL, TUV, CE, CB.

Fast and flexible response of individual requirement, efficient customer service.

SPECIFICATIONS

Rated voltage	250V
Rated current	5A/10A/16A
Bimetal Disc	1/2 Inch/φ12.8mm
Operating Temperture Range	45°C-300°C/113°F-572°F
Reset type	Automatic Reset
Shell Material	Ceramics
Electric Strength	AC1500V 50/60hz-0.5mA/1min
Resistance	≤50mΩ
Insulation Resistance	≥100MΩ(DC500V)
Complies with RoHS and REACH
