KSD-500-3

The kettle controller is used as a connector between the base of the electric kettle and the upper seat, with the functions like dry burn protection, water loading function on the bottom or handle, steam sensor switch, temperature sensor, and water level sensing. It is mainly used in circuit connection and temperature protection of electric kettles, health pots, milk blenders, tea boilers, electric tea pots, tea bar machines and other equipment. Product parameters: Voltage: 125V/250V Current: 10A/13A Safety Certification: CQC, CB, CE, TUV

Detailed Description

Advantage

30 years’ experience of temperature control research, manufacture and customer service.

Achieved automatic mechanized production and integration of the supply chain.

Industry-leading production capacity. The annual production is over 300 million units and continuously increasing.

Stringent quality control and full inspection

Products are compliant with EU RoHs Directive and certified by CQC, ,VDE, UL, TUV, CE, CB.

Fast and flexible response of individual requirement, efficient customer service.



SPECIFICATIONS

       Rated voltage               240V
       Rated current               10A/13A
       Maximumambient temperature               125℃
       Service life               10000
Withstand voltage        AC2200V 1minute
Number of terminals        5 Pole



PRODUCT FEATURES

Dry burn protection: self-resetting

CERTIFICATION

Keyword: KSD-500-3
