5x30 Probes

NTC temperature sensor is a thermistor housing with extended leads. It confirms the corresponding temperature by measuring the change in its resistance value. This temperature sensor is mainly used in motors, industrial equipment, kitchen appliances, carp batteries and other equipment, as an important part of temperature transmission and monitoring. Security Certification: CQC

Product Consulting

Detailed Description

Advantage

30 years’ experience of temperature control research, manufacture and customer service.

Achieved automatic mechanized production and integration of the supply chain.

Industry-leading production capacity. The annual production is over 300 million units and continuously increasing.

Stringent quality control and full inspection

Products are compliant with EU RoHs Directive and certified by CQC, ,VDE, UL, TUV, CE, CB.

Fast and flexible response of individual requirement, efficient customer service.

SPECIFICATIONS

K value	R25=10k±1%
B value	B25/85=3435K±1%
σ Dissipation coefficient (in air)/mW/℃	3
τ Time constant (in water)/s	≤10
Insulation resistance	≥100MΩ
Voltage withstand test 1500VAC0.5mA/1min	No flashover and no breakdown
Operating temperature range/℃	-30～125
